OpenTenBase Database Management System

OpenTenBase is an advanced enterprise-level database management system based on prior work of Postgres-XL project. It supports an extended subset of the SQL standard, including transactions, foreign keys, user-defined types and functions. Additional, it adds parallel computing, security, management, audit and other functions.

OpenTenBase has many language interfaces similar to PostgreSQL, many of which are listed here:

https://www.postgresql.org/download

A OpenTenBase cluster consists of multiple CoordinateNodes, DataNodes, and GTM nodes. All user data resides in the DataNode, the CoordinateNode contains only metadata, the GTM for global transaction management. The CoordinateNodes and DataNodes share the same schema.

Users always connect to the CoordinateNodes, which divides up the query into fragments that are executed in the DataNodes, and collects the results.

The latest version of this software may be obtained at:

https://github.com/OpenTenBase/OpenTenBase

For more information look at our website located at:

https://www.opentenbase.org/

Memory: 4G RAM minimum

OS: TencentOS 2, TencentOS 3, OpenCloudOS, CentOS 7, CentOS 8, Ubuntu

yum -y install gcc make readline-devel zlib-devel openssl-devel uuid-devel bison flex

or

apt install -y gcc make libreadline-dev zlib1g-dev libssl-dev libossp-uuid-dev bison flex

mkdir /data
useradd -d /data/opentenbase -s /bin/bash -m opentenbase # add user opentenbase
passwd opentenbase # set password

git clone https://github.com/OpenTenBase/OpenTenBase

export SOURCECODE_PATH=/data/opentenbase/OpenTenBase
export INSTALL_PATH=/data/opentenbase/install

cd ${SOURCECODE_PATH}
rm -rf ${INSTALL_PATH}/opentenbase_bin_v2.0
chmod +x configure*
./configure --prefix=${INSTALL_PATH}/opentenbase_bin_v2.0 --enable-user-switch --with-openssl --with-ossp-uuid CFLAGS=-g
make clean
make -sj
make install
chmod +x contrib/pgxc_ctl/make_signature
cd contrib
make -sj
make install

Notice: if you use Ubuntu and see initgtm: command not found while doing "init all", you may add ${INSTALL_PATH}/opentenbase_bin_v2.0/bin to /etc/environment

Use PGXC_CTL tool to build a cluster, for example: a cluster with a global transaction management node (GTM), a coordinator(COORDINATOR) and two data nodes (DATANODE).

1. Install pgxc and import the path of pgxc installation package into environment variable.

   PG_HOME=${INSTALL_PATH}/opentenbase_bin_v2.0
   export PATH="$PATH:$PG_HOME/bin"
   export LD_LIBRARY_PATH="$LD_LIBRARY_PATH:$PG_HOME/lib"
   export LC_ALL=C


2. Disable SELinux and firewall (optional)

   vi /etc/selinux/config # set SELINUX=disabled
   # Disable firewalld
   systemctl disable firewalld
   systemctl stop firewalld


3. Get through the SSH password free login between the machines where the cluster node is installed, and then deploy and init will SSH to the machines of each node. After getting through, you do not need to enter the password.

   ssh-keygen -t rsa
   ssh-copy-id -i ~/.ssh/id_rsa.pub destination-user@destination-server


1. Generate and fill in configuration file pgxc_ctl.conf. pgxc_ctl tool can generate a template for the configuration file. You need to fill in the cluster node information in the template. After the pgxc_ctl tool is started, pgxc_ctl directory will be generated in the current user's home directory. After entering " prepare config" command, the configuration file template that can be directly modified will be generated in pgxc_ctl directory.

   • The pgxcInstallDir at the beginning of the configuration file refers to the installation package location of pgxc. The database user can set it according to his own needs.

   pgxcInstallDir=${INSTALL_PATH}/opentenbase_bin_v2.0


   • For GTM, you need to configure the node name, IP, port and node directory.

   #---- GTM ----------
   gtmName=gtm
   gtmMasterServer=xxx.xxx.xxx.1
   gtmMasterPort=50001
   gtmMasterDir=${GTM_MASTER_DATA_DIR}/data/gtm_master


   • If you do not need gtmSlave, you can directly set it to 'n' in the configuration of the corresponding node.

   gtmSlave=n


   If you need gtmSlave, configure it according to the instructions in the configuration file.

   • Coordination node, which needs to be configured with IP, port, directory, etc.

   coordNames=(cn001)
   coordMasterCluster=(opentenbase_cluster)
   coordPorts=(30004)
   poolerPorts=(30014)
   coordPgHbaEntries=(0.0.0.0/0)
   coordMasterServers=(xxx.xxx.xxx.2)
   coordMasterDirs=(${COORD_MASTER_DATA_DIR}/data/cn_master/cn001)


   • Data node, similar to the above nodes: IP, port, directory, etc. (since there are two data nodes, you need to configure the same information as the number of nodes.)

   primaryDatanode=dn001
   datanodeNames=(dn001 dn002)
   datanodePorts=(20008 20009)
   datanodePoolerPorts=(20018 20019)
   datanodeMasterCluster=(opentenbase_cluster opentenbase_cluster)
   datanodePgHbaEntries=(0.0.0.0/0)
   datanodeMasterServers=(xxx.xxx.xxx.3 xxx.xxx.xxx.4)
   datanodeMasterDirs=(${DATANODE_MASTER_DATA_DIR}/data/dn_master/dn001 ${DATANODE_MASTER_DATA_DIR}/data/dn_master/dn002)


   There are coordSlave and datanodeSlave corresponding to the coordination node and data node. If not, configure them as 'n'; otherwise, configure them according to the configuration file.

   In addition, two type ports: poolerPort and port, need to be configured for coordinator node and datanode. poolerPort is used by nodes to communicate with other nodes. port is the port used to login to the node. Here, poolerPort and port must be configured differently, otherwise there will be conflicts and the cluster cannot be started.

   Each node needs to have its own directory and cannot be created in the same directory.

2. Distribution of installation package(deploy all). After filling in the configuration file, run the pgxc_ctl tool，and then input "deploy all" command to distribute the installation package to the IP machine of each node.

3. Initialize each node of the cluster(init all). After the distribution of the installation package is completed, input "init all" command in pgxc_ctl tool to initialize all the nodes in the configuration file pgxc_ctl.conf and start the cluster. So far, the cluster has been started.

$ psql -h ${CoordinateNode_IP} -p ${CoordinateNode_PORT} -U ${pgxcOwner} -d postgres

postgres=# create default node group default_group  with (dn001,dn002);
CREATE NODE GROUP
postgres=# create sharding group to group default_group;
CREATE SHARDING GROUP
postgres=# create table foo(id bigint, str text) distribute by shard(id);

https://docs.opentenbase.org/

Tencent

The OpenTenBase is licensed under the BSD 3-Clause License. Copyright and license information can be found in the file LICENSE.txt

Thanks for all contributors here: CONTRIBUTORS
